UMAX TWO AC

Description

Our new electric UMAX puts the power in PowerTech AC. Prepare yourself for an energy-efficient electric solution that features smooth acceleration and unrivaled hill-climbing ability like you’ve never experienced before. Our electric cars make battery power synonymous with horsepower, while giving your players a silky smooth ride. The UMAX Two is just as strong, resourceful, and reliable as the UMAX One, but additionally equipped with an even more substantial cargo bed. Measuring in at 41″ long, 46″ wide, and 12″ deep, your maintenance team will have even more volume to work with.

• MOTOR: 48-volt AC
• OUTPUT RATING: 6.7 hp (5.0 kW FOR 60 minutes)
• MOTOR CONTROL UNIT: NEOS 350 amp AC controller by Toyota Industries Corporation
• BATTERIES: Standard: Eight 6-volt Trojan T-105 Batteries
• PERFORMANCE: Maximum Forward Speed—19.5 mph (31.4 km/h)
  Maximum Reverse Speed—17.5 mph (28 km/h)
  Minimum Turning Radius—3.98 m

  DIMENSIONS: Overall Length—119.37 in (303.2 cm)

  Overall Width—49.33 in (125.3 cm)

  Overall Height (with suntop)—71.81 in (182.4 cm)

  Overall Height (without suntop)—48.54 in (123.3 cm)

  Wheelbase—77.2 in (196.1 cm)

  Front Wheel Tread—40.27 in (102.3 cm)

  Rear Wheel Tread—40.19 in (102.1 cm)

  Minimum Ground Clearance—4.52 in (11.5 cm)

  FRAME: HybriCore™ chassis features a robotic welded automotive ladder-style steel frame protected with a multi-step full-immersion phosphate treatment, electro-deposition epoxy-based coating, and an electrostatic applied polyester/urethane powder topcoat

  BODY: Custom-formulated thermoplastic olefin painted with a two-part top coat of high-luster automotive-grade polyurethane

  STEERING: Self-compensating double reduction helical rack-and-pinion

  FRONT WHEEL SUSPENSION: Tru-Trak II™ fully independent automotive-style strut suspension

  REAR WHEEL SUSPENSION: Unit swing arm with DUAL RATE coil springs over hydraulic shock absorbers

  BRAKES: Self-adjusting mechanical, front and rear wheel drum brakes
